Description
The Model 1224 threads a wide range of pipe including black, galvanized and plastic-coated pipe, together with stainless steel, IMC and heavy-wall conduit, as well as rod up to 30 Rockwell C.
INCLUDES:
• (1) 1/2" - 4" NPT Hammer Chuck Machine
• (1) 26132 711 SO Universal Right Hand Dies
• (1) 26152 714 SO Receding Right Hand Dies
• (1) 26192 Dies. 1224 2 - 1/2" - 4 NPT HS
• (1) 47745 1/2" - 3/4" Universal Alloy Die Set
• (1) 47750 1" - 2" Universal Alloy Die Set
• (1) 26212 1/4"-4" Wheel-Type Cutter
• (1) 26217 1/4"-4" Blade-Type Reamer
• (1) 33125 Wheel, Cutter F229 3 & 4 HD
• (1) 46030 3/16" Hex Key
• (1) 46040 Key, Hex 7/32
• (1) 46190 Hex Key, 1/4"
• (1) 70835 Nu-Clear Thread Cutting Oil
• (1) 83975 Wrench, 3/4 COMB
• (1) 53693 Tool Box
FEATURES:
• Induction motor for constant speed, optimal torque & noise reduction.
• 12 or 36-RPM g for optimal machine performance.
• Integral through-head oiling system floods the thread lubricating the dies and clearing the chips.
• Includes 1/4 - 2" inch and 2-1/2 - 4 inch Die Heads.
• Mount on a workbench or RIDGID stand (sold separately).
SPECIFICATIONS:
• Nominal Pipe Capacity: 1/4"-2" (6mm-100mm) @ 36 RPM, 2-1/2"-4" (65mm-100mm) @ 12 RPM, 4"-6" (100mm-150mm) with 161 Geared Threader
• Bolt Capacity: 1/4"-2" (6mm-50mm)
• Motor Control: Reverse/off/forward, heavy-duty rotary-type and integral foot switch
• Gear Box: Two-speed gear box with a 3:1 ratio
• Chuck: Hammer-type with replaceable rocker-action jaw inserts
• Volts: 240
